Rated voltage: AC100V~240V±10%, 50-60Hz
Light source: OSRAM SIRIUS HID 420W
Color temperature: 8500K, lamp life: 1500 hours
optics
Optical zoom range:
2° to 15°(BEAM mode);
5°~50°(SPOT pattern mode);
8°~52°(WASH dyeing mode) Three modes can be switched at will.
Stroboscopic: double-chip stroboscopic (random pulse stroboscopic), stroboscopic speed 0.5 ~ 9 times/second
Controls
DMX channels: 17/24 international standard DMX channels
Signal input: Standard three-core/five-core signal socket input and output
Control mode: DMX, self-walking, master-slave, voice control
Display: LCD LCD display, touch screen + key control, Chinese and English display interface, built-in gravity sensor.
Console reset function, console switch bubble function
Scanning Angle
Horizontal scanning: X axis: 540°, 16Bit
Vertical scanning: Y-axis: 270°, 16Bit
Patterns and colors
Color tray: 13 colors + white light, can be half color, two-way flow, color conversion and half color rainbow effect.
Rotating pattern disc: 9 optional pattern pieces + white light, each pattern can rotate forward and backward and have a shaking effect, pattern disc with positive and negative fast and slow water effect.
Fixed pattern plate: 14 kinds of patterns + white light, each pattern has a shaking effect, pattern disc with positive and negative fast and slow water effect
Double prism effect: 2 independent rotating prisms, octoprism +16 edge combination, double prisms can be combined with each other or rotated separately.
Atomization: 0% ~ 100% uniform soft light atomization effect.
specification
Protection level: IP20.
Product size: 290 H x 390 W x 650 D mm
Base dimensions :130 H x 390 W x 270 D mm
